PDLO394-XW Iconic Outdoor Outlet Single 10A H White
PDL Iconic Outdoor PDLO394-XW single switched socket, 10A 250V, horizontal Extra White finish with IP54 protection. Ideal for outdoor electrical installations.
Original price was: $60.00.$56.04Current price is: $56.04.
Guaranteed Safe Checkout
Features & Compatibility
The PDL Iconic Outdoor PDLO394-XW Single Switched Socket is a robust outdoor power outlet designed for residential and commercial electrical installations. Rated at 10A, 250V AC, this single switched socket provides a reliable and convenient power connection for outdoor areas.
Part of the trusted PDL Iconic Outdoor range, the PDLO394-XW features a horizontal wall-mounted design and a clean Extra White finish, making it suitable for modern homes, commercial buildings and outdoor electrical installations.
Integrated shutters help seal the socket apertures when not in use, supporting its IP54 protection rating. This makes the socket suitable for outdoor applications where protection against dust and water splashes is required.
The socket uses a single rocker switch for simple ON/OFF operation and features a 1P + E outlet configuration with an Australian/New Zealand socket standard. Installation is by screw mounting, with three screw terminals and connection capacity for 3 × 2.5mm² or 2 × 4mm² conductors.
With dimensions of 115.5mm wide × 85mm high × 70mm deep, the PDLO394-XW provides a practical surface-mounted solution without taking up excessive wall space. The unit weighs approximately 0.22kg.
The PDL Iconic Outdoor PDLO394-XW is manufactured using durable polycarbonate, ABS and POM materials and is designed for outdoor installation. It complies with AS/NZS 3112 and carries RCM certification.
Whether you’re installing an outdoor power point on a deck, patio, garage, workshop or exterior wall, the PDL Iconic Outdoor PDLO394-XW provides a practical combination of functionality, protection and modern styling.
Order the PDL Iconic Outdoor PDLO394-XW from Trade Haven today.
Key Specifications
| Specification | Details |
|---|---|
| Brand | PDL |
| Range | Iconic Outdoor |
| Product Code | PDLO394-XW |
| Product Type | Single Switched Socket |
| Rated Current | 10A |
| Rated Voltage | 250V AC |
| Frequency | 50Hz |
| Socket Configuration | 1P + E |
| Number of Outlets | 1 |
| Switch Type | Rocker |
| Switch Function | ON/OFF |
| Mounting | Wall Mounted |
| Mounting Position | Horizontal |
| Installation | Outdoor |
| Protection Rating | IP54 |
| Colour | Extra White |
| Finish | Matt |
| Terminals | 3 Screw Terminals |
| Connection Capacity | 3 × 2.5mm² / 2 × 4mm² |
| Socket Standard | Australian/New Zealand |
| Standard | AS/NZS 3112 |
| Certification | RCM |
| Material | Polycarbonate / ABS / POM |
| Width | 115.5mm |
| Height | 85mm |
| Depth | 70mm |
| Net Weight | 0.22kg |
| Warranty | 18 months |
Features & Benefits
- 10A 250V rated switched socket
- IP54 protection for outdoor applications
- Integrated shutters help protect socket apertures
- Modern Extra White matt finish
- Horizontal surface/wall-mounted design
- Single rocker ON/OFF switch
- Australian/New Zealand socket standard
- Suitable for residential and commercial installations
- Complies with AS/NZS 3112
- RCM certified
- Durable polycarbonate, ABS and POM construction
Ideal Applications
- Outdoor power points
- Decks and patios
- Garages
- Workshops
- Exterior walls
- Residential outdoor areas
- Commercial outdoor installations
- Renovation and new-build electrical projects
Additional information
| Weight | .2 kg |
|---|
